ZX-4RR
The Ninja ZX-4RR delivers exceptional performance with cutting-edge technology and aggressive styling.
READ MOREMODEL OVERVIEW
CONCEPT
NEW MODEL
ZX-4RR
The Ninja® ZX™-4R ABS mounts a 399cc in-line 4-cylinder engine with class-leading performance in a compact chassis with proportions similar to smaller displacement models. On the track or on the street, experience the exhilaration of the Ninja ZX-4R ABS supersport's unprecedented power, intoxicating high-rpm wail, and sharp, nimble handing that will awaken the dormant supersport within you.
READ MORE
SPECS
TECHNICAL SPECIFICATIONS
Engine
4-stroke, in-line 4-cylinder, DOHC, 16-valve, liquid-cooled
Displacement
399cc
Bore x Stroke
57.0 x 39.1mm
Compression Ratio
12.3:1
Fuel System
DFI® with 34mm throttle valves (4)
Ignition
TCBI with Digital Advance
Starting
Electric
Transmission
6-speed, return shift
Final Drive
Chain
Electronic Rider Aids
Economical Riding Indicator, Kawasaki TRaction Control (KTRC) (3-mode), Power Modes, Anti-lock Brake System (ABS)
Maximum Power
57.0 kW {77 PS} / 14,500 rpm
Maximum Torque
39.0 N•m {4.0 kgf•m} / 13,000 rpm
Front Suspension
37mm inverted Showa fork with SFF-BP internals
Rear Suspension
Horizontal back-link, Showa shock w/ adjustable spring preload
Front Tire
120/70 ZR17 M/C (58W)
Rear Tire
160/60 ZR17 M/C (69W)
Front Brakes
Dual 290mm semi-floating discs with radial-mount 4-piston monobloc caliper and ABS
Rear Brakes
Single 220mm disc with single-piston caliper and ABS
Frame Type
Trellis, high-tensile steel
Rake / Trail
97 mm
Overall Length
1,990 mm
Overall Width
765 mm
Overall Height
1,110 mm
Ground Clearance
135 mm
Seat Height
800 mm
Curb Weight
189 kg
Fuel Capacity
15 litres
Wheelbase
1,380 mm
